| M/b is brand new. OEM packaging. No accessories (cables, driver CD's, backplate) are included. Just the board itself.
Genuine Acer part. Motherboard will fit into a standard ATX case. Please follow CPU compatibility guide.
30 days warranty back-to-base.
|
CPU
|
Socket Intel (LGA 1155)
* Core i7 (Quad), Core i5
* Core i3, Pentium (Dual Core)
IntelG520, G530, G620, G630, i5-2300 to 2500, i7-2600
|
|
Chipset
|
Intel H67
|
|
Integrated Graphics
|
Intel HD
|
|
Memory
|
2 * 240-pin DDR3 DIMM slots – Dual Channel DDR3 1333 non-ECC , un-buffered memory (Max 16GB)
|
|
Expansion Slots
|
1 * PCI Express x16 (2.0)
3 * PCI Express x1
|
|
Storage
|
4 * SATA II 3Gb/s connectors
|
|
Audio
|
Realtek – High Definition
|
|
Ethernet
|
Intel Gigabit – 10/100/1000Mb/s
|
|
Rear Panel
|
1 * PS/2 green color for mouse
1 * PS/2 purple color for keyboard
1 * RJ45 LAN Port
6 * USB 2.0 Ports
1 * VGA Port
1 * HDMI Port
1 * Audio I/O
|
|
Internal
|
1 * 4-pin CPU Fan connector
1 * 3-pin SYS Rear Fan connector
1 * 4-pin ATX 12V Power connector
1 * 24-pin ATX Power connector
1 * Clear CMOS jumper
1 * Front Audio header
1 * Front Panel header
3 * USB headers
|
|
Form Factor
|
Micro-ATX
|
| Brand: |
Acer |
| Socket type: |
LGA 1155/Socket H2 |
| Form Factor: |
Micro-ATX |
| Compatible CPU: |
IntelG520, G530, G620, G630, i5-2300 to 2500, i7-2600 |
| Expansion slots: |
PCI Express x16PCI Express x1 |
| Type of memory: |
DDR3 SDRAM |
| Number of memory slots: |
2 |
|
|
|
