Number of Screens

1

Viewable Screen Size

23.8"

Screen Mode

Full HD

Panel Technology

Vertical Alignment (VA)

Response Time

1 ms

Aspect Ratio

16:9

Pixel Pitch

0.27 mm

Horizontal Viewing Angle

178°

Vertical Viewing Angle

178°

Backlight Technology

LED

Mount Type

Wall Mountable

Horizontal Frequency

• 31 kHz to 84.50 kHz - VGA
• 31 kHz to 112.50 kHz - HDMI 1.4

Vertical Frequency

• 75 Hz
• 48 Hz to 100 Hz - HDMI 1.4

Tilt Angle

-5° to 15°

Adjustable Display Pivot

No

Active Display Area (mm)

527x296

Frequency (Horizontal/Vertical)

• VGA:31KHz-84.5KHz/75Hz
• HDMI 1.4:31KHz-112.5KHz/48Hz-100Hz

VESA Mount Compatible

Yes

VESA Mount Standard

75 x 75

Colour

Black

Height

320 mm

Width

539 mm

Depth

41 mm

Height with Stand

398 mm

Width with Stand

539 mm

Depth with Stand

189 mm

Weight (Approximate)

2.39 kg

Weight with Stand (Approximate)

2.64 kg

Maximum Resolution

1920 x 1080

Standard Refresh Rate

100 Hz

Colour Supported

16.7 Million Colours

Colour Depth

6-bit+FRC

Dynamic Contrast Ratio

100,000,000:1

Brightness

250 cd/m²

Color Gamut

72% NTSC

Native Contrast Ratio

3,000:1

Package Contents

• 1 x SB242Y H Widescreen LCD Monitor
• 1 x HDMI Cable
• 1 x Power Cord (Australia)

HDMI

Yes

HDMI Version

1.4

VGA

Yes

Standby Power Consumption (Energy Star)

500 mW

Off-Mode Power Consumption (Energy Star)

300 mW

Maximum Power Consumption (Energy Star)

30 W

Operating Power Consumption (Energy Star)

18 W
