Technical Information

Number of Screens

1

Viewable Screen Size

23.8"

Screen Mode

Full HD

Panel Technology

In-plane Switching (IPS) Technology

Response Time

4 ms

Aspect Ratio

16:9

Pixel Pitch

0.27 mm

Horizontal Viewing Angle

178°

Vertical Viewing Angle

178°

Backlight Technology

LED

Mount Type

Wall Mountable

Maximum Adjustable Height

120 mm

Swivel Angle

-45° to 45°

Tilt Angle

-5° to 25°

Adjustable Stand Height

Yes

Adjustable Display Pivot

Yes

Audio

Speakers

Yes

Speaker Output Power

2 W

Physical Characteristics

VESA Mount Compatible

Yes

VESA Mount Standard

100 x 100

Colour

Black

Height

323 mm

Width

540 mm

Depth

65 mm

Height with Stand

499 mm

Width with Stand

540 mm

Depth with Stand

193 mm

Weight (Approximate)

3.64 kg

Weight with Stand (Approximate)

5.59 kg

Video

Maximum Resolution

1920 x 1080

Standard Refresh Rate

100 Hz

Colour Supported

16.7 Million Colours

Brightness

250 cd/m²

Tearing Prevention Technology

Adaptive Sync

Miscellaneous

Package Contents

• B247Y Widescreen LCD Monitor
• 1 x HDMI Cable
• Power Cord
• 1 x VGA Cable

Environmentally Friendly

Yes

Environmental Certification

TCO Certified

Interfaces/Ports

HDMI

Yes

DisplayPort

Yes

Number of DisplayPorts

1

VGA

Yes

Power Description

Operating Power Consumption (Energy Star)

15 W

Input Voltage

• 120 V AC
• 230 V AC
