AUO B156HAN06.1 HW1A Mechanical Details

Pixel Features :

Resolution
1920(RGB)×1080, FHD
Dot Pitch(mm)
0.05975×0.17925 (H×V)
Pixel Format
RGB Vertical Stripe
Pixel Pitch(mm)
0.17925×0.17925 (H×V)  [141PPI]

Mechanical Size :

Active Area(mm)
344.16(H) × 193.59(V)
Bezel Area(mm)
-
Outline Dim.(mm)
359.5(H) × 223.8(V)
Depth(mm)
3.05/3.2 (Typ./Max.)

Outline Features :

Form Style
Flat Rectangle
Shape Style
Slim (PCBA Flat, T≤3.2mm)
Aspect Ratio
16:9 (H:V)
Orientation
Landscape type

Mounting :

Face mounting holes (8 pcs) on up, down slugs

Other Spec :

Weight
350g (Max.)
Treatment
Antiglare

Disclaimer : Inputted by panelook engineers according to datasheet, but we cannot guarantee the spec listed is entirely correct.

AUO B156HAN06.1 HW1A Optical Details

Basic Information :

Luminance(cd/m²)
250 (Typ.)
Contrast Ratio
700:1 (Typ.) (Transmissive)
Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
Display Mode
AHVA, Normally Black, Transmissive
Best View on
Symmetry
Response(ms)
25 (Typ.)(Tr+Td)

Color Performance :

White Coordinate
Wx:0.313; Wy:0.329
Display Colors
262K (6-bit)
Color Temperature
6485K
White Uniformity
1.25/1.60 (Max.)(5/13 points)

1931 Color Gamut :

NTSC Ratio
47%
sRGB
65% coverage
Adobe RGB
49% coverage
DCI-P3
48% coverage
Rec.2020
35% coverage
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
