13.3" BOE NV133FHM-N62 IPS Full HD Screen 30-pin Matte Non-Touch KL.1330E.003
Specifications
Specifications
| Connector |
30-pin |
| Display Technology |
LED LCD |
| Custom Bundle |
No |
| Screen Finish |
Matt |
| Screen Size |
13.3 in |
| MPN |
NV133FHM-N62 |
| Brand |
BOE |
| Type |
IPS |
| Aspect Ratio |
16:9 |
| Modified Item |
No |
| Compatible Brand |
Universal |
| Maximum Resolution |
1920 x 1080 |
| Non-Domestic Product |
No |
Product Description
-
- Brand
- BOE
- Model P/N
- NV133FHM-N62
- Diagonal Size
- 13.3"
- Panel Type
- a-Si TFT-LCD, LCM
- Resolution
- 1920(RGB)×1080, FHD 166PPI
- Pixel Format
- RGB Vertical Stripe
- Active Area
- 293.76(W)×165.24(H) mm
- Bezel Opening
- -
- Outline Dim.300.26(H)×187.45(V)×2.5(D) mm
- Treatment-
- Luminance300 cd/m² (Typ.)
- Contrast Ratio800:1 (Typ.) (TM)
- View DirectionSymmetry
- Response Time30 (Typ.)(Tr+Td)
- Viewing Angle85/85/85/85 (Typ.)(CR≥10)
- Operating ModeADS, Normally Black, Transmissive
- Support Color262K 72% NTSC
- Light SourceWLED [9S4P] , 15K hours , With LED Driver
- Form StyleSlim (PCBA Flat, T≤3.2mm)
- Frame Rate60Hz
- Touch PanelWithout
- Interface Type
- eDP (2 Lanes) , 30 pins Connector
- Power Supply
- 3.3V (Typ.)
- Environment
- Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
