13.3" AUO B133HAN04.1 IPS Full HD Laptop Screen Matte Non-Touch KL.13305.027
Specifications
Specifications
| Connector |
40-pin |
| Display Technology |
LED LCD |
| Custom Bundle |
No |
| Screen Finish |
Matte |
| Screen Size |
13.3 in |
| Brand |
AUO |
| Aspect Ratio |
16:9 |
| Compatible Brand |
Universal |
| Modified Item |
No |
| Type |
IPS |
| MPN |
B133HAN04.1 |
| Maximum Resolution |
1920 x 1080 |
| Non-Domestic Product |
No |
Product Description
- Brand
- AUO
- Model P/N
- B133HAN04.1 HW2A
- Diagonal Size
- 13.3"
- Panel Type
- a-Si TFT-LCD, LCM
- Resolution
- 1920(RGB)×1080, FHD 166PPI
- Pixel Format
- RGB Vertical Stripe
- Active Area
- 293.472(W)×165.078(H) mm
- Bezel Opening
- -
- Outline Dim.
299.972(W)×177.48(H)×4.5(D) mm
- Treatment
Antiglare
- Luminance
300 cd/m² (Typ.)
- Contrast Ratio
800:1 (Typ.) (TM)
- View Direction
Symmetry
- Response Time
27 (Typ.)(Tr+Tf)
- Viewing Angle
85/85/85/85 (Typ.)(CR≥10)
- Operating Mode
AHVA, Normally Black, Transmissive
- Support Color
262K 46% NTSC
- Light Source
WLED , 15K hours , With LED Driver
- Form Style
Slim (PCBA Bent, T≤3.0mm)
- Frame Rate
60Hz
- Touch Panel
Without
- Interface Type
- eDP (2 Lanes) , eDP1.3 , 30 pins Connector
- Power Supply
- 3.3V (Typ.)
- Environment
- Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
